Denon AVC-X3800H 9.4 Channel A/V Receiver with HEOS

Multichannel Surround
DTS HD Master, DTS:X, DTS:X Pro
Yes, Yes, No

DTS Neo:X, DTS Neural:X No, Yes

DTS Virtual:X Yes

IMAX Enhanced Yes

Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualisation, Dolby Atmos Music Yes, Yes, Yes, Yes

Dolby ProLogic Ilz, Dolby Surround No, Yes

Auro 3D Yes

360 Reality Audio / MPEG H Yes, Yes

Multichannel Stereo Yes

Max. Number of Processing (Pre-Amp) Channels 11.4

Sound Enhancements
Discrete Power Amplifier Yes

Pure Direct Yes

Audyssey MultEQ XT32
Audyssey Dynamic EQ, Dynamic Volume Yes, Yes

Audyssey LFC Yes

Dirac Live Upgradability Yes

Compressed Audio Restorer Yes

Network
Media Server Yes

HEOS Wireless Multi-Room Technology Yes

Alexa / Google Voice Assistant / Apple HomePod Yes, Yes, Yes

Lossy Formats: MP3, WMA, AAC Yes, Yes, Yes

Lossless Formats: FLAC, ALAC, WAV Yes, Yes, Yes

Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit) Yes, Yes, Yes

DSD Audio Streaming Yes (2.8/5.6MHz)

AirPlay 2 Yes

TuneIn Yes

Spotify Connect Yes

Pandora Yes

SiriusXM* Yes

Roon Tested Yes

HEOS App Control Yes

Compatible with Remote APP for Smart Phones Denon 2016 AVR Remote
Ethernet Ports Yes

Wi-Fi Yes

Bluetooth Yes

HDMI
HDMI Inputs: Back, Front 6, No

HDCP2.3 support Yes

HDMI Outputs: Main, Zone 2, 1

HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB Yes, Yes

HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR Yes , Yes, Yes, Yes, Yes

ALLM (Auto Low Latency Mode) Pass-through for gaming Yes

Variable Refresh Rate, Quick Flame Transport, Quick Media Switching Yes, Yes, No

3D Signal Pass-through Yes

8K Signal Pass-Through, Scaling, GUI Overlay Yes, Yes, Yes

DSD Audio Capability Yes

Audio Return Channel (ARC), Enhanced ARC Yes, Yes

Auto LipSync Yes

Multi-room CI

Multi-Room Zones 2

Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog Yes (2ch),

Yes (2ch), Yes, Yes

Zone Audio Output: Speaker, Pre-Out Yes, Yes

Zone HDMI Output from HDMI Source Yes

IP Control, RS232 Control, Web Control, App Control Yes, Yes /Yes, Yes

Remote In / Out Yes, Yes

DC Trigger Output 1

HDMI Diagnostics Yes

Others
Auto Speaker Setup by Microphone Audyssey MultEQ XT32
Dirac Live (upgrade)
Front Display 1-Line FLD

GUI Languages 3

Setup Assistent Yes

Quick Select Plus, Quick Select Yes, No

Variable Crossover Yes

Optimised Bass Redirection Yes

Bass Sync Yes

ECO Mode Yes

Auto Power Off Yes

Sleep Timer Yes

Inputs Outputs

HDMI In, Out 6, 3

Multi-Room Video Out: Video, HDMI No, Yes

Analog In, Out 5, No

Phono (MM) In Yes

Digital In: Optical, Coaxial 2, 2

Multi-Room Out: Analog, Digital 1, No

Multichannel Preout Yes (11.4)

Subwoofer Out 4 (independent)

Speaker Terminal: Gold-Plated Screw, Regular Screw No, Yes

Number of Speaker Terminals 11

Speaker A / B Assignable

Bi-amp Drive Assignable

Multi-Room Speaker Terminal Assignable

Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB No, No, No, No, Yes

USB Audio, Made for iPod, Made for iPhone Yes, No, No

AM/FM Tuner Yes

Specifications
Number of Power Amps 9

Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) 105W

Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 135W

Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 215W

General
System Remote Control RC-1253

Pre-Programmed, Learnable, LCD Display No, No, No

Power Consumption in W 660W

Power Consumption No-Sound (ECO On / Off) in W 60W/100W

Standby Consumption in W 0.1

CEC Standby Consumption in W 0.5

Network Standby Consumption in W Less than 2.0

Maximum Dimensions

Antenna: Horizontal: (W x D x H) in Inches

Antenna: Vertical: (W x D x H) in Inches

W/O Antenna: (W x D x H) in Inches 17.1 x 15.3 x 6.6
( 17.1 x 15.3 x 9.3 )
【 17.1 x 14.9 x 6.6 】

Weight in LBS 27.6

Weight in LBS (Packaging) 33.3
