Introducing the world’s first tube-based data clocking device: the SuperTubeClockâ˘
By incorporating a low-noise mini-triode vacuum tube into the digital clock, this boldly conceived design provides vastly superior resolution, detail retrieval, improved clarity, increased definition and detail from top to bottom.
Dual Mono Topology
Per channel dedicated tubes. While it is fine to use a single tube as a buffer for both channels and claim your DAC is “tube”, it can’t be compared to the PrimaLuna design and what it does for the music.
Vacuum Tube Rectified
Vacuum tube rectified power supply incorporates eleven separate power supply regulation circuits. Tube rectification is synonymous with organic sound, especially when compared to DACs being known as sounding like “a computer”.
USB Digital Input
USB digital input allows using your computer for storage and playback of your music with all the benefits of features like playlists and easier access to your whole music library. Rather than just add in an USB input as an afterthought, PrimaLuna engineers searched endlessly looking for the best-sounding USB interface we could find. Our USB input converts the jitter-filled USB digital signal to S/PDIF, dramatically improving the digital signal quality before it gets to the SuperTubeClock. This USB input is a true high-resolution digital input.
EVO 100 Tube DAC Specifications
Price | $4295 |
Inputs | USB AES/EBU Coax Optical |
Outputs | Stereo RCA |
PCM (all inputs) |
16bit-24bit 44.1kHz-192kHz |
DSD (USB) DSD (other inputs) |
DSD64-DSD128 (DoP) DSD64 (DoP) |
DAC | TI (Burr Brown) PCM1792A |
24bit/192kHz Upsampling |
TI (Burr Brown) SRC4192 |
Tube Complement | 2 – 12AX7 2 – 12AU7 2 – 5AR4 |
Dimensions (W x H x D) | 11″ x 7.5″ x 15.9″ |
Weight | 28.7 lbs |
