Key Features
Features 3 operational modes:
– 4×4 Seamless Switching Matrix (HDMI or VGA inputs)
– Video Wall (2×2, 4×1 or 1×4 configuration)
– Multi-Viewer mode with preset layouts
Features 4x video inputs that can be configured as HDMI video or VGA video with associated L/R analogue audio
Instantaneous seamless video switching (Matrix and Video Wall modes)
Video inputs support industry standard video resolutions including VGA-WUXGA (up to 1920×1200 @60Hz) and 480i-4K (3840×2160 @30Hz 4:4:4, 4096×2160 @24Hz 4:4:4)
HDMI output resolution fixed to 1080p @60Hz
Supports HDMI 2ch PCM audio only
Discreet IR routing
Supplied with Blustream IR receivers and emitters
Control via front panel, IR, RS-232, TCP/IP and the Blustream Matrix App
3rd party control drivers available for all major home control brands
Advanced EDID management
HDCP1.4 compliant
