SYSTEM
3 way, full para-aperiodic vented box “Stealth Ultraflex System” technology

LOUDSPEAKERS
Tw: H28 XTR3-04 DAD Arrow Point, Ø 28 mm
Md: M15 XTR-08 Neodymium Magnet System, Ø 150 mm
W: 2 x W18XTR-08, Ø 180 mm

CROSS-OVER
250 Hz – 2500Hz

FREQUENCY RESPONSE
40 Hz – 35.000 Hz, Stealth reflex included

SENSITIVITY
89 db SPL (2.83V/1 m)

NOMINAL IMPENDANCE
4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT
50W – 350W, without clipping

LONG-TERM MAX INPUT VOLTAGE (IEC 268-5)
20 V rms

DIMENSIONS (HxWxD)
315 x 836 x 385 mm
12,4 x 32,9 x15 in

WEIGHT
35 Kg – net weight
77 lb – net weight
