Denon AVR-X2800H 7.2 Channel 8K A/V Receiver with HEOS

Multichannel Surround
DTS HD Master, DTS:X, DTS:X Pro
Yes, Yes, No

DTS Neo:X, DTS Neural:X
No, Yes

DTS Virtual:X
Yes

Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualisation, Dolby Atmos Music
Yes, Yes, Yes, Yes

Dolby ProLogic Ilz, Dolby Surround
No, Yes

Multichannel Stereo
Yes

Max. Number of Processing (Pre-Amp) Channels
7.1

Sound Enhancements
Discrete Power Amplifier
Yes

Pure Direct
Yes

Audyssey MultEQ XT
Audyssey Dynamic EQ, Dynamic Volume
Yes, Yes

Compressed Audio Restorer
Yes

Network
Media Server
Yes

HEOS Wireless Multi-Room Technology
Yes

Alexa / Google Voice Assistant / Apple HomePod
Yes, Yes, Yes

Lossy Formats: MP3, WMA, AAC
Yes, Yes, Yes

Lossless Formats: FLAC, ALAC, WAV
Yes, Yes, Yes

Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit)
Yes, Yes, Yes

DSD Audio Streaming
Yes (2.8/5.6MHz)

AirPlay 2
Yes

TuneIn
Yes

Spotify Connect
Yes

Pandora
Yes

SiriusXM*
Yes

Roon Tested
Yes

HEOS App Control
Yes

Compatible with Remote APP for Smart Phones Denon 2016 AVR Remote
Ethernet Ports
Yes

Wi-Fi
Yes

Bluetooth
Yes

HDMI
HDMI Inputs: Back, Front
6, No

HDCP2.3 support
Yes

HDMI Outputs: Main, Zone
2, No

HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB
Yes, Yes

HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR
Yes , Yes, Yes, Yes, Yes

ALLM (Auto Low Latency Mode) Pass-through for gaming
Yes

Variable Refresh Rate, Quick Flame Transport, Quick Media Switching
Yes, Yes, No

3D Signal Pass-through
Yes

8K Signal Pass-Through, Scaling, GUI Overlay
Yes, Yes, Yes

Audio Return Channel (ARC), Enhanced ARC
Yes, Yes

Auto LipSync
Yes

Multi-room CI
Multi-Room Zones
2

Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog
Yes (2ch), Yes (2ch), Yes, Yes

Zone Audio Output: Speaker, Pre-Out
Yes, Yes

IP Control, RS232 Control, Web Control, App Control
Yes, Yes /Yes, Yes

Remote In / Out
Yes, Yes

HDMI Diagnostics
Yes

Others
Auto Speaker Setup by Microphone Audyssey MultEQ XT
Front Display 1-Line FLD
GUI Languages 3
Setup Assistent Yes
Quick Select Plus, Quick Select Yes, No
Variable Crossover Yes
Optimized Bass Redirection Yes
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes
Inputs Outputs
HDMI In, Out 6, 2
Multi-Room Video Out: Video, HDMI No, No
Analog In, Out 4, No
Phono (MM) In Yes
Digital In: Optical, Coaxial 2, 1
Multi-Room Out: Analog, Digital 1, No
Multichannel Preout Yes (0.2)
Subwoofer Out 2
Speaker Terminal: Gold-Plated Screw, Regular Screw No, Yes
Number of Speaker Terminals 7
Speaker A / B Assignable
Bi-amp Drive Assignable
Multi-Room Speaker Terminal Assignable
Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB No, No, No, No, Yes
USB Audio, Made for iPod, Made for iPhone Yes, No, No
AM/FM Tuner Yes

Specifications
Number of Power Amps 7
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) 95W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 125W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 185W

General
System Remote Control RC-1253
Pre-Programmed, Learnable, LCD Display No, No, No
Power Consumption in W 500
Power Consumption No-Sound (ECO On / Off) in W 35W/75W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Standby Consumption in W Less than 2.0
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches 17.1 x 13.4 x 6.6
( 17.1 x 13.4 x 9.3 )
【 17.1 x 13.0 x 6.6 】
Weight in LBS 21.0
Weight in LBS (Packaging) 25.4
